Name: HP DesignJet T1600dr 36-in PostScript Printer
Brand: HP
SKU: 3EK13A
Availability: InStock

Description

Technical details

HP DesignJet T1600dr 36-in PostScript Printer

Functions

Print speed, maximum

180 D/hr, 19.3 sec/D[1]

Resolution (color)

Up to 2400 x 1200 optimized dpi

Print Technology

HP Thermal Inkjet

Number of print cartridges

6 (C, M, Y, G, pK, mK)

Product disclaimer

This printer is intended to work only with cartridges that have a new or reused HP chip, and it uses dynamic security measures to block cartridges using a non-HP chip. Periodic firmware updates will maintain the effectiveness of these measures and block cartridges that previously worked. A reused HP chip enables the use of reused, remanufactured, and refilled cartridges.

Compatible ink types

Dye-based (C, M, Y, pK, G); pigment-based (mK)

Print languages

Adobe PostScript 3, Adobe PDF 1.7, HP-GL/2, HP-RTL, TIFF, JPEG, CALS G4

Mobile Printing Capability

Direct print from mobile apps on iOS, Android, and Chrome OS; email printing with HP ePrint and HP Smart app for iOS and Android

Connectivity, standard

Gigabit Ethernet (1000Base-T), Wi-Fi (with optional Jetdirect accessory), supporting the following standards: TCP/IP, BootP/DHCP (IPv4 only), DHCPv6, TFTP (IPv4 only), SNMP (v1, v2c, v3), Apple Bonjour Compatible, WS Discovery, Embedded Web Server (HTTP, HTTPS), IPsec, SMTP (email), Raw IP printing (9100), LPD, IPP, WS print, NTLM v2, SMBv3, SSL/TLS, 802.1X authentication (LEAP, PEAP, EAP-TLS), DFS

Network ready

Standard

Memory, standard

128 GB (file processing)[4]

Hard disk

500 GB self-encrypting removeable

Non-printable area (cut-sheet)

0.12 x 0.87 x 0.12 x 0.12 in

Line accuracy

±0.1%[2]

Finished output handling

Sheet feed, two automatic front-loading roll feeds, smart roll switching, integrated output stacker[3], media bin, automatic horizontal cutter

Media sizes supported

A, B, C, D, E

Media sizes supported

A4, A3, A2, A1, A0

Media sizes, custom

8.3 x 11 to 36 x 48 in

Media types

Bond and coated paper (bond, coated, heavyweight coated, super heavyweight plus matte, colored), technical paper (natural tracing, translucent bond, vellum), film (clear, matte, polyester), photographic paper (satin, gloss, semi-gloss, matte, high-gloss), backlit, self-adhesive (two-view cling, indoor paper, polypropylene, vinyl)

Media sizes, standard

11 to 36 in

Roll external diameter

5.5 in

Media thickness

Up to 19.7 mil

Power

Input voltage (auto ranging) 100-240 V (±10%), 50/60 Hz (±3 Hz), 2 A max

Power consumption

100 W (printing); <36 W (ready); <10 W (sleep); 0.3 W (off)

Operating temperature range

41 to 95ºF

Warranty

One-year limited hardware warranty

Software included

HP Click App, HP mobile, ePrint and iOS/Android support plus the HP Smart app for mobile, HP Web Jetadmin, HP JetAdvantage Security Manager, HP SmartTracker (optional), HP Click Driver for Windows 11

Dimensions (W X D X H)

55 x 30 x 43 in

Weight

187 lb

Package weight

258 lb

What’s in the box

HP DesignJet T1600 Printer, printer stand and media bin, spindles (x2), printheads, introductory ink cartridges, user guide, power cords

Recommended Media

C6810A HP Bright White Inkjet Paper (FSC® certified)[5] (recyclable)[6] 914 mm x 91.4 m (36 in x 300 ft); C6980A HP Coated Paper (PEFC™ certified)[5] (recyclable)[6] 914 mm x 91.4 m (36 in x 300 ft); L5C80A HP Universal Heavyweight Coated Paper, 3-in Core (FSC® certified)[5] (recyclable)[6] 914 mm x 91.4 m (36 in x 300 ft); D9R28A HP Everyday Matte Polypropylene, 3-in Core 914 mm x 61 m (36 in x 200 ft)

Dynamic security

Dynamic security enabled printer

Certain HP printers are intended to work only with cartridges that have a new or reused HP chip or electronic circuitry. These printers use dynamic security measures to block cartridges using a non-HP chip or electronic circuitry. Periodic firmware updates will maintain the effectiveness of these measures and block cartridges that previously worked. Reused HP chips and electronic circuitry enable the use of reused, remanufactured, and refilled cartridges.
